317L Stainless Steel Plate - UNS S31703 / 1.4438 SS Plates Width 1000mm 1250mm 1500mm 2000mm

Brand Name : DELTA

Model Number : 317L

Certification : ISO

Place of Origin : China

MOQ : 400 kgs

Price : 2400 -3220 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : wooden pallets + waterproof paper

Products : stainless steel plates

Grade : 317L

Standard size : 1000*2000mm 1219*2438mm 1500*6000mm

Thickness : 1.0 - 30.0mm

Brand : TISCO BAOSTEEL POSCO LISCO

Loading Port : Shanghai Port

MOQ : 200 kgs

Packing : wooden pallets + waterproof paper

Contact Now

317L Stainless Steel Plate - UNS S31703 / 1.4438 SS Plates Width 1000mm 1250mm 1500mm 2000mm

Material
200 300 400 Series stainless steel
Grade
201 202 301 303 304 304L 2205 2507 309 309S 310 310S 314 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L
Standard
AISI ASTM JIS DIN EN BS
Tech
Cold rolled / Hot rolled
Thickness
Hot rolled: 3mm-16mm 16-150mm
Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0
As per customer's request: 16-150mm
Cold rolled: 0.3-6mm
Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0
As per customer's request: 4.0/5.0/6.0
Width&Length
1000mm-6000mm, or as per customer's request
Hot rolled: 1250*3000mm (4.1*10ft) 1500*3000mm (5*10ft)
1250*6000mm (4.1*19.6ft) 1500*6000mm (5*19.6ft)
1800*6000mm (5.9*19.6ft) 2000*6000mm(6.5*19.6ft)
Cold rolled: 1000*2000mm (3.2*6.5ft) 1219*2438mm (4*8ft)
1500*3000mm (5*10ft)
1800 available 2000 available
Place of Origin
Jiangsu China
Processing Service
Bending, Welding, Recoiling, Punching, Cutting
Tolerance
±1%
Surface Treatment
N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc
Payment
T/T terms, 30% pre-payment, 70% balance see B/L copy LC Western Union Paypal
Delivery Time
5-15 days for ordinary orders (standard orders <=50 ton); specified orders needs final confirmation as per customer's request

Designed as per international and national standards, these UNS S31700, S31703 Sheet & Plate are offered in customized length sizes and shapes to our esteemed clients. Also referred as WNR 1.4449, 1.4438 Sheet & Plate these are available at best possible rates in the market.
We are an authorized Dealer, as well as Supplier of Stainless Steel 317 / 317L Sheet & Plate of various Approved Manufacturing companies like Jindal Steel Works, Acreinox, Columbus Stainless, Outokumpu, Thyssenkrupp etc.

SS 317 / 317L SHEETS AND PLATES SPECIFICATIONS :

Dimensions 317L Stainless Steel Plate
Standard ASTM A240 / ASME SA240
Width 1000mm, 1219mm, 1500mm, 1800mm, 2000mm
Thickness 4mm-40mm
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm,
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finish 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc

EQUIVALENT GRADES FOR STAINLESS STEEL 317 / 317L SHEET & PLATE

STANDARD WERKSTOFF NR. UNS JIS EN
SS 317 1.4449 S31700 SUS 317 –
SS 317L 1.4438 S31703 SUS 317L X2CrNiMo18-15-4

CHEMICAL COMPOSITION OF SS 317 / 317L SHEETS & PLATES

Grade C Mn Si P S Cr Mo Ni Fe
SS 317 0.08 max 2.0 max 1.0 max 0.045 max 0.030 max 18 – 20 3 – 4 11 – 15 57.845 min
SS 317L 0.035 max 2.0 max 1.00 max 0.045 max 0.030 max 18 – 20 3 – 4 11 – 15 57.89 min

MECHANICAL PROPERTIES FOR SS 317 / 317L SHEETS & PLATES

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
7.9 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

TYPES OF SS 317 / 317L SHEET & PLATE

  • Stainless Steel 317 Cold Rolled Sheets Supplier
  • 317L Stainless Steel Sheets and Plates Dealer
  • SS 317 Round Sheet Exporter
  • 317L Stainless Steel Cold Rolled Plates
  • ASME SA240 SS Sheet Stockist
  • Stainless Steel SA240 TP317L Embossed Plates
  • UNS S31703 Cold Rolled Plates
  • 1.4438 SS Sheets Manufacturer
  • AISI 317 Steel Sheets / Plates
  • TP 317L SS Embossed Sheets Manufacturer in India
  • Stainless Steel 317 Hot Rolled Plates
  • ASTM A240 TP317 Cold Rolled Sheet Supplier in Saudi Arabia
  • UNS S31700 SS Finish Plates Stockist in Riyadh
  • ASTM A240 TP317 Finish Stainless Sheet
  • 317 Austenitic Stainless Steel 2D Finish Sheets
  • Stainless Steel 317 Sheet / Plates / Coils Exporter
  • SS 317L Plates Dealer
  • 317 Stainless Steel Plates Stockholder
