Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets

Name: Alloy 317L EN 14438 Stainless Steel Plate amp Sheets Cold Rolled SS Plate Sheets
Brand: DELTA
Price: 2400 USD

China Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets wholesale

Brand Name : DELTA

Model Number : 317L

Certification : ISO

Place of Origin : China

MOQ : 400 kgs

Price : 2400 -3220 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : wooden pallets + waterproof paper

Products : stainless steel plates

Grade : 317L

Standard size : 1000*2000mm 1219*2438mm 1500*6000mm

Thickness : 1.0 - 30.0mm

Brand : TISCO BAOSTEEL POSCO LISCO

Loading Port : Shanghai Port

MOQ : 200 kgs

Packing : wooden pallets + waterproof paper

Contact Now

Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets

Material	200 300 400 Series stainless steel
Grade	201 202 301 303 304 304L 2205 2507 309 309S 310 310S 314 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L
Standard	AISI ASTM JIS DIN EN BS
Tech	Cold rolled / Hot rolled
Thickness	Hot rolled: 3mm-16mm 16-150mm Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0 As per customer's request: 16-150mm Cold rolled: 0.3-6mm Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0 As per customer's request: 4.0/5.0/6.0
Width&Length	1000mm-6000mm, or as per customer's request Hot rolled: 12503000mm (4.110ft) 15003000mm (510ft) 12506000mm (4.119.6ft) 15006000mm (519.6ft) 18006000mm (5.919.6ft) 20006000mm(6.519.6ft) Cold rolled: 10002000mm (3.26.5ft) 12192438mm (48ft) 15003000mm (510ft) 1800 available 2000 available
Place of Origin	Jiangsu China
Processing Service	Bending, Welding, Recoiling, Punching, Cutting
Tolerance	±1%
Surface Treatment	N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc
Payment	T/T terms, 30% pre-payment, 70% balance see B/L copy LC Western Union Paypal
Delivery Time	5-15 days for ordinary orders (standard orders <=50 ton); specified orders needs final confirmation as per customer's request

Alloy 317L is a low-carbon stainless steel with increased additions of chromium, nickel and molybdenum for better corrosion resistance than type 316L. This steel resists attack from sulphurous, acetic, formic, citric and tartaric acids as well as combatting the tendency to pit when in contact with phosphorous acid, chlorides, bromides and iodides.

Standard Specification of 317L Stainless Steel Products

Type	Sizes	Schedules	ASTM Standards
Bar	1/2″ thru 6″		A276, A479
Butt Weld Fittings	1/2″ thru 12″	Sch 10, 40, 80, 160 & XXH	A403
Forgings			A182
Pipe Welded & Seamless	1/4″ thru 16″	Sch 10, 40, 80, 160 & XXH	A312
Tube, Welded			A249
Tube, Seamless			A213
Plate			A240
Flange & Pressure Fittings	All Descriptions

Stainless Steel 317L Plate Thickness

Cold rolled ASTM A240 317L thin plate	0.2-4mm
Hot rolled SS 317L medium plate	4-20mm
Hot rolled 317L SS thick plate	20-60mm
Hot rolled AISI 317L extra thick plate	60-115mm

317L Material Equivalent

STANDARD	UNS	WERKSTOFF NR.
SS 317L	S31703	1.4438

Applications

Alloy 317 and 317L stainless steel is a low-carbon, corrosion resistant steel used to handle sulfur, pulp liquor, acid dyestuffs, acetylating and nitrating mixtures, bleaching solutions, severe coal and oil smoke, and many chemical compounds. 317 & 317L Stainless steel pipe, flanges and fittings are typically found in:

Paper and pulp handling equipment
Textile equipment
Food-processing equipment

Alloy 317L / EN 1.4438 Stainless Steel Plate & Sheets Cold Rolled SS Plate Sheets
