ASTM / EN / JIS Standard Stainless Steel Plates 321 321H Thickness 0.6 - 80.0mm from TISCO
| Material | 200 300 400 Series stainless steel |
| Grade | 201 202 301 303 304 304L 2205 2507 309 309S 310 310S 314 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L |
| Standard | AISI ASTM JIS DIN EN BS |
| Tech | Cold rolled / Hot rolled |
| Thickness | Hot rolled: 3mm-16mm 16-150mm Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0
As per customer's request: 16-150mm Cold rolled: 0.3-6mm
Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0
As per customer's request: 4.0/5.0/6.0 |
| Width&Length | 1000mm-6000mm, or as per customer's request
Hot rolled: 1250*3000mm (4.1*10ft) 1500*3000mm (5*10ft)
1250*6000mm (4.1*19.6ft) 1500*6000mm (5*19.6ft)
1800*6000mm (5.9*19.6ft) 2000*6000mm(6.5*19.6ft)
Cold rolled: 1000*2000mm (3.2*6.5ft) 1219*2438mm (4*8ft)
1500*3000mm (5*10ft)
1800 available 2000 available |
| Place of Origin | Jiangsu China |
| Processing Service | Bending, Welding, Recoiling, Punching, Cutting |
| Tolerance | ±1% |
| Surface Treatment | N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc |
| Payment | T/T terms, 30% pre-payment, 70% balance see B/L copy LC Western Union Paypal |
| Delivery Time | 5-15 days for ordinary orders (standard orders <=50 ton); specified orders needs final confirmation as per customer's request |
AISI 321 Stainless Steel (SS321), 321H, TP321
AISI 321 stainless steel (SS321) is basically type 304 with the addition of titanium (Ti), which stabilizes carbides against sensitization to prevent intergranular precipitation of chromium carbide when the steel is heated to a temperature within the sensitization range (such as during welding). 321H is to obtain the best creep strength and creep rupture strength. TP321 stainless steel is for seamless, welded, and heavily cold worked pipes.
Grade 321 Stainless Steel Datasheet
The following tables and lists give grade 321 stainless steel datasheet and specification including chemical composition, physical properties and mechanical properties, machinability, heat treatment, welding, etc.
Chemical Composition
SS 321 stainless steel chemical composition is listed in the following table based on cast analysis.
| Chemical Composition, % |
| ASTM Type | AISI Type (UNS) | C, ≤ | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | N, ≤ | Other Elements | Notes |
| ASTM A240/A240M | 321 (UNS S32100) | 0.08 | 0.75 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 5×(C+N), ≤ 0.70 | Plate, Sheet, and Strip for Pressure Vessels |
| ASTM A276A/276M | 1.00 | – | Stainless Steel Bars and Shapes |
| ASTM A580/A580M | – | ≥ Ti 5×C | Stainless Steel Wire |
| ASTM A959 | 0.10 | ≥ Ti 5×(C+N), ≤ 0.70 | Wrought Stainless Steels |
| ASTM A473 | – | ≥ Ti 5×C | Stainless Steel Forgings |
| ASTM A314 | – | ≥ Ti 5×(C+N), ≤ 0.70 | Billets and bars for forging |
| ASTM A240/A240M | 321H (UNS S32109) | 0.04-0.10 | 0.75 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 4x(C+N), ≤ 0.70 | Plate, Sheet, and Strip |
| ASTM A959 | 1.00 | 0.10 | Wrought Stainless Steels |
| ASTM A312/A312M | TP321 (UNS S32100) | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 5×(C+N), ≤ 0.70 | Stainless Steel Pipes |
| TP321H (UNS S32109) | 0.04-0.10 | 1.00 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.10 | ≥ Ti 4x(C+N), ≤ 0.70 |
AISI 321 Stainless Steel Properties
The tables below list AISI 321 stainless steel properties, including physical and mechanical properties.
Physical Properties
AISI 321 steel physical properties are given in the following lists, including density, thermal expansion, elastic modulus, thermal conductivity, specific heat capacity and electrical resistance.
Mechanical Properties
AISI 321 stainless steel mechanical properties are listed in the following tables.
| SS 321 Mechanical Properties |
| ASTM | AISI Type (UNS) | Conditions | Tensile Strength, MPa (ksi), ≥ | 0.2% Yield Strength, MPa (ksi), ≥ | Elongation in 50 mm (2 in.), %, ≥ | Reduction of Area, %, ≥ | Brinell Hardness (HBW), ≤ | Rockwell Hardness (HRBW), ≤ | Product forms |
| ASTM A276/A276M | 321 (UNS S32100) | Annealed, Hot finished | 515 (75) | 205 (30) | 40 | 50 | – | – | Bars and Shapes |
| Annealed, Cold finished, Dia ≤ 12.7 mm (0.5 in.) | 620 (90) | 310 (45) | 30 | 40 | – | – |
| Annealed, Cold finished, Dia > 12.7 mm (0.5 in.) | 515 (75) | 205 (30) | 30 | 40 | – | – |
| ASTM A580/A580M | Annealed | 520 (75) | 210 (30) | 35 | 50 | | | Wire |
| Cold finished | 620 (90) | 310 (45) | 30 | 40 | – | – |
| ASTM A473/A473M | Annealed, Sections ≤ 5 in. (127 mm) | 515 (75) | 205 (30) | 40 | 50 | – | – | Forgings |
| Annealed, Sections > 5 in. (127 mm) | 70 (485) |
| ASTM A240/A240M | 321, 321H (UNS S32109) | – | 515 (75) | 205 (30) | 40 | – | 201 | 92 | Plate, Sheet, and Strip |
Applications
Type 321, 321H and TP321 can be used in places where solution treatment after welding is not possible, such as steam lines and superheater pipes and exhaust systems in reciprocating engines and gas turbines with temperatures ranging from 425 to 870 °C (800 to 1600 °F). And fuel injection lines and hydraulic systems for aircraft and aerospace vehicles.
AISI 321 Stainless Steel Equivalent
AISI TP321, 321H and 321 stainless steel equivalent to European EN (German DIN EN, British BSI EN, France NF EN), ISO, Japanese JIS and Chinese GB standard (for reference).
| AISI 321 stainless steel equivalent material |
| US | European Union | ISO | Japan | China |
| Standard | AISI Type (UNS) | Standard | Grade (Steel Number) | Standard | ISO Name (ISO Number) | Standard | Grade | Standard | Grade |
AISI SAE;
ASTM A240/A240M; ASTM A276A/276M; ASTM A959 | 321 (UNS S32100) | EN 10088-2; EN 10088-3 | X6CrNiTi18-10 (1.4541) | ISO 15510 | X6CrNiTi18-10 (4541-321-00-I ) | JIS G4321;
JIS G4304;
JIS G4305;
JIS G4309; | SUS321 | GB/T 1220;
GB/T 3280 | 0Cr18Ni10Ti;
06Cr18Ni11Ti (new designation) (S32168) |
| 321H (UNS S32109) | X7CrNiTi18-10 (1.4940) | X7CrNiTi18-10 (4940-321-09-I ) | SUS321H | 1Cr18Ni11Ti;
07Cr19Ni11Ti (new designation) (S32169) |
| ASTM A312/A312M | TP321 | EN 10216-5; EN 10217-7; | X6CrNiTi18-10 (1.4541) | ISO 9329-4 | X6CrNiTi18-10 | JIS G3459;
JIS G3463 | SUS321TP | GB/T 14975;
GB/T 14976 | 0Cr18Ni10Ti;
06Cr18Ni11Ti (new designation) (S32168) |
