Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel

Brand Name : TISCO

Model Number : 316L

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 1300 - 1480 USD/Ton

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Stainless Steel Sheet

Grade : 316L

Standard : ASTM EN JIS GB

Size : 1219*2438mm

Thickness : 0.5 - 3.0mm

Type : cold rolled

Service : cutting, surface treatment

application : auto exhaust pipe

Packing : wooden pallets

Contact Now

Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel

Products Specification

Products Name 316L Stainless Steel Sheet
Standard ASTM EN JIS GB BIS
Thickness

0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm
Surface 2B 2D NO.1 or process other surface as request
Standard Size 1219*2438mm 1000*2000mm
Service Slit Cutting, bending , surface treatment
Other Grade 200 Series: 201 202
300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347
400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446
Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy
MOQ 500 kgs
Packing Wooden Pallets and waterproof paper

Introduce of 316L Stainless Steel

Grade 316L is very similar to 316 stainless steel. It is still considered a molybdenum-bearing grade and has properties that make it highly resistant to corrosive degradation. 316L grade stainless steel differs from 316 in that contain lower levels of carbon. The decreased level of carbon in this stainless steel makes this grade immune from sensitisation or grain boundary carbide precipitation. Because of this unique property, Grade 316L tends to be commonly used in heavy gauge welding situations. Additionally, the lower carbon levels make this grade easier to machine. Like 316 stainless steel, 316L because of its austenitic structure is extremely tough, even in the most extreme of temperatures.

More details of 316L Stainless Steel Sheets

Products 316 stainless steel sheet/plate
Width 500-2000mm
Length 1000-12000mm
Thickness Cold Rolled:0.3-3 mm, Hot Rolled:3-120mm
Materials 316
Standard ASTM A240 ,ASTM A167,ASTM A176,GB/T3280,JIS4304, EN10088-2,etc
Surface Finish No.1, No.4, 2B, BA, HL, No.8, Mirror finish, and so on.

Composition Specification (%):

Grade C Mn And P S Cr Mo In N
316 min. max. – 0.08 2.0 – 0.75 – 0.045 – 0.030 18.0 3.00 14.0 – 0.10
316L min. max. – 0.030 –

2.0

 – 0.75 – 0.045 – 0.030 16.0

18.0

 2.00

3.00

 10.0

14.0

 – 0.10
316H min. max. 0.10 –

2.0

 – 0.75 – 0.045 – 0.030 16.0

18.0

 2.00

3.00

 10.0

14.0

 –

–

Mechanical Property Specification:

Grade Tensile Strength (MPa)

min

 Yield Strength 0.2% Proof (MPa)

min

 Elongation (% in 50mm)

min

 Hardness
Rockwell B (HR B)

max

 Brinell (HB)

max
316 515 205 40 95 217
316L 485 170 40 95 217
316H 515 205 40 95 217
316H also has a requirement for a grain size of ASTM No 7 or coarser.

DIMENSION FOR STOCK SHEET

No. T*W*L(mm) No. T*W*L(mm) No. T*W*L(mm)
1 0.3*1000*2000 20 1.5*1219*2438 39 24.0*1500*6000
2 0.3*1219*2438 21 2.0*1000*2000 40 25.0*1500*6000
3 0.4*1000*2000 22 2.0*1219*2438 41 30.0*1500*6000
4 0.4*1219*2438 23 2.5*1000*2000 42 35.0*1500*6000
5 0.5*1000*2000 24 2.5*1219*2438 43 40.0*1500*6000
6 0.5*1219*2438 25 3.0*1000*2000 44 45.0*1500*6000
7 0.6*1000*2000 26 3.0*1219*2438 45 50.0*1500*6000
8 0.6*1219*2438 27 3.0*1500*6000 46 55.0*1500*6000
9 0.7*1000*2000 28 4.0*1500*6000 47 60.0*1500*6000
10 0.7*1219*2438 29 5.0*1500*6000 48 65.0*1500*6000
11 0.8*1000*2000 30 6.0*1500*6000 49 70.0*1500*6000
12 0.8*1219*2438 31 8.0*1500*6000 50 75.0*1500*6000
13 0.9*1000*2000 32 10.0*1500*6000 51 80.0*1500*6000
14 0.9*1219*2438 33 12.0*1500*6000 52 85.0*1500*6000
15 1.0*1000*2000 34 14.0*1500*6000 53 90.0*1500*6000
16 1.0*1219*2438 35 16.0*1500*6000 54 95.0*1500*6000
17 1.2*1000*2000 36 18.0*1500*6000 55 100.0*1500*6000
18 1.2*1219*2438 37 20.0*1500*6000 56 105.0*1500*6000
19 1.5*1000*2000 38 22.0*1500*6000 57 110.0*1500*6000

Low Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless SteelLow Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless SteelLow Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless SteelLow Carbon 316L Stainless Steel Sheets EN 1.4404 SS Sheets AISI316L/ SUS316L Stainless Steel
