ASTM A240 Grade 317L Stainless Steel Plate & Sheet Hot Rolled NO.1 Surface 3.0 - 16.0mm Thickness

Brand Name : DELTA

Model Number : 201 202 218 304 316L 309S 310S 317L 321 347 904L 2205 2507 925 926.etc

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 2400 - 3500 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : wooden pallets + waterproof paper

Products : stainless steel sheet & plate

Grade : 201 202 218 304 310S 310H 316L 317L 409L 430.etc

Standard size : 1000*2000mm 1219*2438mm 1500*6000mm

Thickness : 0.6 - 60.0mm

Brand : TISCO BAOSTEEL POSCO LISCO

Loading Port : Shanghai Port

MOQ : 500 kgs

Packing : wooden pallets + waterproof paper

Contact Now

ASTM A240 Grade 317L Stainless Steel Plate & Sheet Hot Rolled NO.1 Surface 3.0 - 16.0mm Thickness

More Specification of 317L Stainless Steel Plate

Products Stainless Steel Plate
Thickness 0.6 - 60.0mm
Width 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request
Length 2000mm 2438mm 3000mm 6000mm or other length as request
Grade 201 202 301 304 304L 304H 309S 310S 310H 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO Nitronic 60 925 926.etc
Service Laser Cutting, Surface processing, bending
Brand TISCO BAOSTEEL POSCO LISCO JISCO
Standard ASTM JIS GB DIN EN BS
Certificate ISO MTC C/O F/E
Packing Wooden pallets and waterproof paper
Deliver time 5 - 15 days
Loading port Shanghai Port

About 317L Stainless Steel Plate

Alloy 317L is a low-carbon, high molybdenum austenitic stainless steel with a higher nickel alloy content than 316L. Developed to resist the attack of sulfuric acid compounds, this alloy combines good corrosion resistance with excellent mechanical properties and ease of fabrication. These alloys are frequently used for flue gas desulfurization services in fossil-fuel power plants. Compared to other austenitic stainless steels, 317L offers a higher creep strength, stress to rupture, and tensile strength at elevated temperatures.

The higher molybdenum and chromium content of 317L provides excellent corrosion resistance compared to stainless steel grades like 304 or 316, and it resists phosphoric acid, sulfuric acid, and chloride pitting/crevice corrosion. The low carbon content of this grade of 317 also provides resistance to sensitization during welding, which allows it to maintain its corrosion resistance at grain boundaries and prevent intergranular stress corrosion cracking.

While 317L cannot be hardened by heat treatment, it can be cold worked.

Standard Inventory Specifications

  • UNS S31703 - 317L
  • ASTM A 240
  • ASTM A182
  • ASTM A167
  • ASME SA 240

Common Applications of 317L

  • Flue gas desulfurization systems found in fossil fuel plants
  • Chemical and Petrochemical Processing
  • Food and Beverage Processing
  • Power Generation — condensers
  • Pulp and Paper Processing
  • Textiles with acid dyes

Features

  • Good corrosion resistance
  • Good mechanical properties
  • Ease of fabrication
  • Produces stronger welds due to lower carbon content
  • Resists the attack of sulfuric acid compounds

*The technical data provided is for information only and not for design purposes. It is not warranted or guaranteed.

Stainless Steel 317L Plate Thickness

Cold rolled ASTM A240 317L thin plate 0.2-4mm
Hot rolled SS 317L medium plate 4-20mm
Hot rolled 317L SS thick plate 20-60mm
Hot rolled AISI 317L extra thick plate 60-115mm

317L Material Equivalent

STANDARD UNS WERKSTOFF NR.
SS 317L S31703 1.4438

ASTM A240 TP 317L Stainless Steel Plate For Sale

Stainless Steel 317L 10mm Plate Stainless Steel Type 317L Plasma Cutting Plate
317L Stainless Steel Sheet Stainless Steel Type 317L Quarto Plate
317L Stainless Steel Foil Rolls ASTM A240 317L Expanded Sheet
ASTM A240 317L Plate ASTM A240 SS 317L Flat Sheet
ASTM A240 Type 317L Coil A240 Tp 317L Bbq Plate
AISI 317L Hot Rolled Plate SS 317L Diamond Plate
ASTM A240 TP 317L Cold Rolled Plate 317L SS Patterned Sheet
SS 317L Clad Plate Stainless Steel AISI 317L Floor Sheet
317L SS Shim Sheet ASTM A240 Type 317L Precision Strip
AISI 317L Stainless Steel Chequered Plate AISI 317L Shims
Grade 317L Stainless Steel Flat Strip ASTM A240 317L Thin Plate
Stainless Steel 317L Perforated Sheet Stainless Steel Grade 317L Shim Stock
Grade 317L Stainless Steel Plate Mill Finish AISI 317L Stainless Steel Rolling Plate
Stainless Steel Grade 317L Plate Mirror Finish Grade 317L Stainless Steel Perforated Plate
SS 317L Sheet No 4 Finish ASTM A240 Type 317L Checker Plate
317L SS Sheet Mirror Finish SS 317L Rolls Sheet
AISI 317L Sheet Brushed Finish 317L SS Chequer Plate
Stainless Steel Grade 317L Hot Rolled Sheet 317L Stainless Steel Tisco Plate
Stainless Steel Type 317L Slitting Coils Stainless Steel 317L Design Sheet
ASTM A240 317L Strips ASTM A240 TP 317L Custom Cut Plate
ASTM A240 Grade 317L Cold Rolled Sheet A240 Tp 317L Tread Plate
A240 Tp 317L Foil Grade 317L Stainless Steel Embossed Plate
Stainless Steel AISI 317L Shim Sheets Stainless Steel Grade 317L 1/4 Inch Plate
ASTM A240 SS 317L Chequered Plate ASTM A240 Grade 317L Hairline Sheet
317L Stainless Steel Polished Plate AISI 317L Stainless Steel Checkered Plate
ASTM A240 Type 317L 2b Finish Sheet Stainless Steel AISI 317L Corrugated Sheet
ASTM A240 TP 317L Sheet Hairline Finish AISI 317L B. Q. Profile
AISI 317L Stainless Steel Plate 2b Finish ASTM A240 TP 317L Etching Sheet
ASTM A240 Grade 317L Plate Brushed Finish ASTM A240 SS 317L Laser Cut Plate

Stainless Steel SA 240 Gr 317L Composition

SS C Mn Si P S Cr Mo Ni Fe
A240 317L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 18.00 - 20.00 3.00 - 4.00 11.00 - 15.00 57.89 min

Stainless Steel 317L Properties

Melting Range Density Tensile Strength (PSI/MPa) Yield Strength (0.2%Offset) (PSI/MPa) Elongation %
1400 °C (2550 °F) 7.9 g/cm3 Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %
