AISI317L Stainless Steel Plate / SA240 UNS S31703 Stainless Steel Application for Desulfurizing Tower

Product Categories
JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

AISI317L Stainless Steel Plate / SA240 UNS S31703 Stainless Steel Application for Desulfurizing Tower

Brand Name : DELTA

Model Number : 201 202 304 316L 309S 310S 317L 321 347 904L 2205 2507.etc

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 2400 - 3500 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : wooden pallets + waterproof paper

Products : stainless steel sheet & plate

Grade : 201 304 310S 310H 316L 317L 430.etc

Standard size : 1000*2000mm 1219*2438mm 1500*6000mm

Thickness : 0.6 - 60.0mm

Brand : TISCO BAOSTEEL POSCO LISCO

Loading Port : Shanghai Port

MOQ : 500 kgs

Packing : wooden pallets + waterproof paper

Contact Now

AISI317L Stainless Steel Plate / SA240 UNS S31703 Stainless Steel Application for Desulfurizing Tower

Products Stainless Steel Plate
Thickness 0.6 - 60.0mm
Width 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request
Length 2000mm 2438mm 3000mm 6000mm or other length as request
Grade 201 202 301 304 304L 304H 309S 310S 310H 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc
Service Laser Cutting, Surface processing, bending
Brand TISCO BAOSTEEL POSCO LISCO JISCO
Standard ASTM JIS GB DIN EN BS
Certificate ISO MTC C/O F/E
Packing Wooden pallets and waterproof paper
Deliver time 5 - 15 days
Loading port Shanghai Port

Our 317L Stainless Steel Plate in Stock

317L Stainless Steel Plate Standard Size In Stock
0.6*1219*2438mm 3.0*1500*6000mm 16.0*1500*6000mm
0.8*1219*2438mm 4.0*1500*6000mm 20.0*1500*6000mm
1.0*1219*2438mm 5.0*1500*6000mm 25.0*1500*6000mm
1.2*1219*2438mm 6.0*1500*6000mm 30.0*1500*6000mm
1.5*1219*2438mm 8.0*1500*6000mm 35.0*1500*6000mm
2.0*1219*2438mm 10.0*1500*6000mm 40.0*1500*6000mm
2.5*1219*2438mm 12.0*1500*6000mm 45.0*1500*6000mm
3.0*1219*2438mm 14.0*1500*6000mm 50.0*1500*6000mm

Stainless steel grade 317L is a low carbon version of grade 317 stainless steel. It has the same high strength and corrosion resistance as 317 steel but can produce stronger welds due to the low carbon content.

Chemical Composition of 317L Stainless Steel

317L Cr Ni Mo Mn Si P S C Fe
Element 18.0-20.0 11.0-15.0 3.0-4.0 2.0 1.0 0.045 0.03 0.03 Balance

Mechanical Properties of 317L Stainless Steel

The mechanical properties of grade 317L stainless steel are displayed in the following table.

Properties Tensile strength Yield strength Modulus of elasticity Elongation at break (in 50 mm) Hardness, Rockwell B
317L 595Mpa 260Mpa 200Gpa 55% 85

Equivalent materials to grade 317L stainless steel

AISI 317L ASTM A167 ASTM A182 ASTM A213 ASTM A240
ASTM A249 ASTM A312 ASTM A774 ASTM A778 ASTM A813
ASTM A814 DIN 1.4438 QQ S763 ASME SA240 SAE 30317L

Applications of 317L Stainless Steel Plate

Grade 317L stainless steel is widely used in the following applications:

  • Condensers in fossil
  • Pulp and paper manufacturing
  • Nuclear fueled power generation stations
  • Chemical and petrochemical process equipment.

AISI317L Stainless Steel Plate / SA240 UNS S31703 Stainless Steel Application for Desulfurizing TowerAISI317L Stainless Steel Plate / SA240 UNS S31703 Stainless Steel Application for Desulfurizing TowerAISI317L Stainless Steel Plate / SA240 UNS S31703 Stainless Steel Application for Desulfurizing TowerAISI317L Stainless Steel Plate / SA240 UNS S31703 Stainless Steel Application for Desulfurizing Tower
