Alloy 254SMO Stainless Steel Plate ASTM A240 UNS S31254 Thickness 0.6 - 30.0mm SS Plate
| Item | 254SMO Stainless Steel Plate |
| Raw Material | Stainless steel sheet (hot rolled and cold rolled) |
| Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, 2205 ,2507,254SMO,253MA.etc. |
| Thickness | 0.6 - 30.0mm |
| Stock Thickness | 0.6mm ,0.8mm,1.0mm,1.2mm,1.5mm.2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25mm,30.0mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as your request |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
254 SMO (UNS S31254, W.N.r 1.4547) Known as it's extremely high resistance to both uniform and localized corrosion.
Our company produce special alloy products, including Bar,Rod,Sheet,Plate,Pipe,Tube Pipe Fittings,Rings,Forgings,Flange Coil and Strip,if any requirements not found, Please email us sales@bealloy.com. We will offer you best price and more details. Any customization are accepted.
| Equivalent designations |
| UNS S31254 |
| DIN W. Nr. 1.4547 |
| Form | ASTM |
| Rod, bar and shape | A 276, A 484 |
| Plate, sheet and strip | A 240, A 480 |
| Seamless and welded pipe | A 312, A 999 |
| Welded pipe | A 814, A 999 |
| Seamless and welded tubing | A 269, A 1016 |
| Fitting | A 403, A 960 |
| Forged or rolled pipe flange and forged fitting | A 182, A 961 |
| Forging | A 473, A 484 |
Chemical composition of 254SMO Stainless Steel
| % | Fe | Cr | Ni | Mo | C | Mn | Si | P | S | Cu | N |
| min | balance | 19.5 | 17.5 | 6.0 | | | | | | 0.50 | 0.18 |
| max | 20.5 | 18.5 | 6.5 | 0.020 | 1.00 | 0.80 | 0.030 | 0.010 | 1.00 | 0.22 |
Physical properties of 254SMO Stainless Steel
| Density | 7.94 g/cm3 |
| Melting range | 1320-1390℃ |
Features: 254 SMO is a high performance austenitic stainless steel. Its high alloying elements content imparts excellent resistance to uniform, pitting and crevice corrosion, and stress corrosion cracking. It was originally developed to withstand the corrosion of acids, especially in the presence of halide ions, such as hydrochloric acid, hydrofluoric acid, phosphoric acid, and sulphuric acid contaminated with chlorides. In certain environments it is an alternative to more expensive nickel alloys and titanium alloys.
Applications: Chemical processing equipment, pulp and paper industry bleaching equipment, desalination plant seawater piping, food and beverage industry, pharmaceuticals, and hydrometallurgy.
